Anderson RBM2000 Round bales

  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
  • Anderson RBM2000 Round bales
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
These self-loading trailers are designed to collect up to 20 round bales of wet or dry hay in a simpler and faster way. Reliable durability and optimum machine handling offers unmatched      efficiency in the field.
Specifications
Model
RBM2000 Round bales
Category Name
Agriculture
Year
2024
Sale Type
New
Manufacturer
Anderson
Tires
550/45-22,5
Controls
Tractor’s hydraulics (option : fingertip joystick)
Tandem Axle
Standard
Safety Chain
Standard
HP Requirements
130 HP
Caméra (de Recul)
Optional
Self-loading Arm Design
Tubular round
Tandem Axle With Brakes
Optional
Self-Steering Axle With Brakes
Optional
Tractor Minimum Hydraulic Flow
2500 psi (172 bar)
Able To Load A Second Row Of Bales
Telescopic
Double Hydraulic Connections Required
4nOrn2 if fingertip joystick option
features and options

    1. High floatation tires.
    2. Adjustable self-loading arm tubular round-shaped designed for bale net protection.
    3. Hydraulic unloading system.
    4. Hydraulic push off system.
    5. Full charge indicator.
    6. Tandem axle.
    7. Rugged frame to support wet bales.
bale
Round bale diameter Up to 6 ft (1,8 m)
Bale type Baleage/dry hay/straw
dimensions
Width – A 8 ft 4 in (2,55 m)
Overall width (inlcuding loading arm) 8 ft 4 in (2,55 m)
Height – B 11 ft 10 in (3,61 m)
Overall height (inlcuding loading arm) 12 pi (3,66 m)
Bed height - E 4 pi 9 po (1,44 m)
Overall length – D 38 pi 5 po (11,76 m)
Overall weight 13450 lb (6100 kg)
Empty Weight on tow bar*** 3205 lb (1455 kg)
capacity
Round bale 4 ft x 4 ftdiameter (1,2 m x 1,2 m) 20
Round bale 4 ft x 5 ft diameter (1,2 m x 1,5 m) 20
Round bale 4 ft x 6 ft diameter (1,2 m x 1,8 m) 20
Round bale 5 ft x 5 ft diameter (1,5 m x 1,5 m) 17
Round bale 5 ft x 6 ft diameter (1,5 m x 1,8 m) 17
Loading arm lifting capacity 2500 lb (1135 kg)
Total weight including load 42 000 lb (19 000 kg)
resource
Name Link
Anderson-brochure-ENG                                                                                                                       Download
